SIZE: 2"~32" (ANSI 150 LBS~ANSI 1500 LBS)

1)Material: WCB, SS304, 304L, 316, 316L
2)Manufacturing to NACE MR-01-75 (On Request)
3)Certificate: ISO9001: 2000
4)Pressure-temp. Rating- ANSI B16.34
5)End flanges: ANSI B16.5 (2"~24"), ASME B16.47 (26" Over)
6)Butt welding ends-ANSI B16.25
7)Suitable Medium: Oil, Nature Gas, Water, Steam, Acid, Alkali, Organic Compounds

Standard:
> Standard compliance: API 6D, BS 1868
> Face to Face: Dimensions: ANSI B16.10
> Pressure Rating: ANSI B16.34
> Inspection and Test: Tested to API 598, BS 6755, Certified to EN10204 3.1B

Materials:
CF8M (SS316), CF8 (SS304) CF3M (SS316L), CF3 (SS304L), DIN 1.4408, SCS 14, WCB 1.0619 Available

Feature:
1. Swing Type Disc
2. Bolted Cover
3. Rising Stem and Non-Rising Handwheel
4. Threaded Seat Ring
5. Renewable Seat Ring

Connection End:
1. RF and RTJ flange ends to ANSI B16.5 or API 605.
2. MSS SP-44 standard.
3. BW flange ends to ANSI B16.25 standard.

Applications:
1. Chemical, Refinery Plant
2. Gas Purification Plant
3. Power Station, Shipbuilding
4. Recycling Facilitites
